Technical Specifications Serial interface: RS-232, RS-422, RS-485; PROFIBUS DP V0 slave interface; 24V DC nominal power supply (21.6-26.4V DC); 300mA maximum current consumption; operating temperature 0°C to +55°C; storage temperature -40°C to +85°C; IP20 enclosure rating.
Functional Features Serial to PROFIBUS DP protocol conversion; configurable serial parameters; supports Modbus RTU, DF1, ASCII and proprietary serial protocols; no programming required; galvanic isolation between serial and PROFIBUS sides.
Application Scenarios Serial device integration into PROFIBUS systems, barcode readers, weigh scales, printers, legacy serial device connection to modern PLC systems.
Performance Parameters Reliable protocol conversion; fast data exchange; low latency; MTBF over 550,000 hours at 30°C.
Material Composition ABS/PC plastic housing, fiberglass communication circuit board, gold-plated D-sub connectors, industrial-grade electronic components.
Structural Characteristics Compact DIN rail mount design; 9-pin D-sub female PROFIBUS connector; serial connector; 2-pole power connector; RJ11 configuration port.
Working Principle Acts as a protocol translator between serial devices and PROFIBUS DP master. It receives data from the serial device, converts it into PROFIBUS DP format, and transmits it to the PLC master; it also converts PROFIBUS output data into serial format for the field device.
