Technical Specifications TFT color touch display; Ethernet communication; Front panel IP65; 24V DC power supply; Operating temperature 0~55°C.
Functional Features Process value display, alarm monitoring, parameter modification, manual operation. Recipe management and event logging.
Application Scenarios Process control, water treatment, power plant, chemical and factory automation as local HMI operator station.
Performance Parameters High contrast TFT display; Touch screen input; Real-time alarm and event recording.
Structural Characteristics Front panel IP65 sealed touch screen, rear metal housing, Ethernet and power terminals, mounting flange for cabinet cutout installation.
Working Principle HMI communicates with ABB AC800M controller via Ethernet, reads process tags and displays on screen; sends operator input commands back to controller.
Installation Requirements Cut cabinet panel cutout, insert HMI and fasten mounting clips. Connect 24V DC power and Ethernet cable. Download HMI project.
Usage Notes Protect front panel from mechanical scratch. Use filtered 24V DC power. Match controller IP address and project version.
