Technical Specifications
| Category | Details |
|---|---|
| Inputs/Outputs | – Speed inputs: 2 redundant channels (supports magnetic pickups, proximity probes) 1. – Analog inputs: 8 channels (4–20 mA, configurable for 27+ functions) 14. – Contact inputs: 20 channels (first 4 default to shutdown/speed control) 1. – Outputs: 2× 4–20 mA control signals; 8× Form-C relay contacts 13. |
| Environmental | – Operating temp: -22°F to 158°F (-30°C to 70°C) 3. – Enclosure: IP54-rated, ATEX-certified, pollution degree 3 3. – EMC Immunity: Compliant with EN 61000-6-2 3. |
| Electrical | – Input voltage: 18–36 VDC (isolated) 3. |
| Interface | – Display: 8.4-inch LCD 3. – Front panel keys: Emergency trip, shift, navigation cross, soft keys, and status LEDs 14. |
4. Applications
Primarily deployed in industrial steam turbines for:
-
Power generation plants: Precision speed/load control during grid synchronization 14.
-
Marine propulsion: Commercial marine-compliant (IACS UR E10) enclosure 3.
-
Critical process industries: Oil/gas, chemical, and manufacturing requiring ATEX-certified safety 3.
5. Certifications & Compliance
-
ATEX (hazardous environment safety) 3.
-
IP54 (dust/water resistance) 3.
-
EN 61000-6-2 (electromagnetic compatibility) 3.
