GE IC697PWR724E

Nominal Rated Voltage: 24 VDC.
Input Voltage Range: 18 to 32 VDC.
Input Power: 160 watts at full load.
Output Power: 90 watts.
Output Voltage and Current: +5 VDC output up to 18 amps; +12 VDC output up to 1.5 amps; -12 VDC output up to 1 amp.
Over - current Protection: 26 A on the 5 V, 4 A on the 12 V, and 2 A on the - 12 V.
Over - voltage Protection: If the 5 V bus goes over 6.7 V, the output is clamped to protect the system.
Ride - through Time: Can keep running for 10 milliseconds even during a full power loss.
Operating Temperature Range: 0 - 60 degrees Celsius.

Tag：

Functional Features

Easy Installation: It has an easy slide – in rack – mount construction and plugs straight into a 48 – pin backplane – mounted connector in the rack’s leftmost slot.
Dual – Rack Operation: Can power a single rack or, if the total load is within the appropriate supply rating, deliver power to a second rack through a prewired cable (part IC697CBL700). Only 5 V power can be supplied to the second rack.
Protection Functions: Provides electronic short – circuit over – current protection on the 5 – volt bus, as well as over – voltage and over – current protection for all outputs, ensuring the safety and stability of the system.

Application Scenarios

Industrial Automation: Widely used in various industrial automation systems, such as manufacturing production lines, to power PLC modules, sensors, and other devices, ensuring the normal operation of the control system.
Process Control: Applicable in industries such as chemical, power, and metallurgy for process control systems, providing stable power for controllers, transmitters, and other equipment in the process.
Building Automation: Can be used in building automation systems, such as HVAC control, lighting control systems, to supply power to related control modules and devices.
