The Anritsu Z-164A (50 Ohm) is a high-precision vector network analyzer module engineered for rigorous RF and microwave testing applications. Designed for telecommunications, electronics manufacturing, and R&D sectors, it delivers exceptional measurement accuracy and reliability in critical industrial environments.
| Parameter | Specification |
|---|---|
| Brand/Model | Anritsu Z-164A |
| Frequency Range | Up to 40 GHz |
| Impedance | 50 Ohms |
| Connector Type | N-Type Male/Female |
| Insertion Loss | ≤ 0.2 dB |
| VSWR | ≤ 1.15:1 |
| Power Rating | 1 W Continuous |
| Dynamic Range | 120 dB |
| Interfaces | USB, LAN, GPIB |
| Operating Temperature | -10°C to +70°C |
Applications & System Integration
Ideal for characterizing RF components including filters, amplifiers, and antennas in aerospace, defense, and telecom infrastructure. The Z-164A integrates seamlessly with Anritsu MS4630B/MS46500B series analyzers and supports automated test environments through SCPI commands. Commonly paired with calibration kits MA9591A and harmonic mixers for extended frequency operations.
